Springs, Coilovers & spring rates? What do our current options have?

RogueIV

Active Member
145
88
28
I'm trying to track what spring rates the current suspension offering have. Currently I have no clue what the rates are on most of the regular lowering springs but here's what I've seen for the current offering of coilovers. Disclaimer: the links provided is where i have pulled my info from, be sure to double check before you purchase. Useage of these links does not mean I endorse them they are merely for reference.

M&S GT-S Coilover AWD F: 7 kg/mm R: 9kg/mm 20way single adjustable damper

M&S GT-S Coilover RWD F: 6 kg/mm R: 9kg/mm 20way single adjustable damper

ARK Performance DT-P F: 7kg/mm R: 10kg/mm 16way single adjustable damper

AutoCrew Coilovers F: 7kg/mm R: 8.5kg/mm 16way single adjustable damper

KW Coilover Kit V3 Pending weights from manufacturer 16way rebound and 12way compression

Here's the current lowering springs on the market, I don't have spring rates for most of these but I do have the stats on how much they'll lower the car.

ARK Performance GT-F - F: Linear 3.2 kg/mm R: Progressive 4.9-5.8 kg/mm- AWD Drop 1.15"F/1.0"R - RWD Drop 0.75"F/0.75"R

ARK Performance GT-S - Unknown spring rate - AWD Drop 1.25F/1.15R - RWD Drop 1"F/1"R

Eibach 3.3T E10-46-035-01-22 - Progressive springs, rate unknown - AWD Drop 1.4"F/1.2"R - RWD Drop 0.8"F/0.8"R

Eibach 2.0T E10-46-035-02-22- Progressive springs, rate unknown - RWD Drop 0.8"F/0.8"R

H&R Sport - rate unknown - Drop (not specified whether it's measured on AWD of RWD) 1.3"F/1.2"R

M&S Storm Line 2.0T - F: 2.77kg/mm R: 7.11kg/mm - Drop (not specified whether it's measured on AWD or RWD) 1.38"F/1.18"R

M&S Storm Line 3.3T - F: 3.03kg/mm R: 7.11kg/mm - Drop (not specified whether it's measured on AWD or RWD) 1.4"F/1.2"R

Storm - rate unknown look to be linear but those may be stock photos - Drop (not specified whether it's measured on AWD or RWD, 2.0 or 3.0) 0.8"F/0.6"R

Godspeed Traction-S LS-TS-KA-0007 (website compromised. not linking) - F: linear 4.25kg/mm R: progressive 6.58-10.22kg/mm - Drop (not specified what model it's measured on) 1.2"F/1.3"R (note: Godspeed is often known as a knock-off brand ymmv)

Megan Racing MR-LS-KST18 - no rate specified - Drop RWD 1.06"F/0.79"R

If you have any more info on these or other offerings let me know and I'll add it into this list.

Last edited:

RogueIV

Active Member
145
88
28
ARK GT-S added
